SENNHEISER EW 100 G4-ME4-B
- Stock: Out Of Stock
- Model: 10254
Wireless Bodypack System with ME 4 Cardio Lavalier Microphone (626 - 668 MHz)
What's Included:
• EM 100 G4 True Diversity Receiver
• SK 100 G4 Bodypack Transmitter
• ME 4 Clip-On Microphone
• GA 3 Rackmount Set
• PS
• 2 AA Batteries
• 2 Rod Antennas
• RJ 10 Cable
EM 100 G4 Specifications:
• Frequency Range: 626 - 668 MHz
• Compander: Sennheiser HDX
• THD: • Weight App: 980 g
• Audio Output: 6.3 mm Jack Socket (Unbalanced) +12 dBu / XLR Socket (Balanced) +18 dBu
• SNR: >/= 110 dBA
• Switching Bandwidth: Up to 42 MHz
• Peak Deviation: +/- 48 kHz
• Nominal Deviation: +/- 24 kHz
• Modulation: Wideband FM
• PS: 12 V DC
• Antenna Connector: 2 BNC Sockets
• Current Consumption: 300 mA
• Adjacent Channel Rejection: Typically >/= 65 dB
• Intermodulation Attenuation: Typically >/= 65 dB
• Receiving Frequency: Max. 1680 Receiving Frequencies, Adjustable in 25 kHz Steps
• RF Sensitivity: < 2.5 microV for 52 dBA eff S/N
• Receiver Principle: True Diversity
• Blocking: >/= 70 dB
SK 100 G4 Specifications:
• Compander: Sennheiser HDX
• THD: • Weigh App.: 160 g
• SNR: >/= 110 dBA
• RF Output Power: Max. 30 mW
• Switching Bandwidth: Up to 42 MHz
• Peak Deviation: +/- 48 kHz
• Nominal Deviation: +/- 24 kHz
• Operating Time: Typically 8 h
• Modulation: Wideband FM
• PS: 2 AA Batteries, 1.5 V or BA 2015 Accupack
• Input Impedance: 40 kOhms, Unbalanced / 1 MOhm
• Max. Input Voltage: 3 Veff
• Powering: 3 V Battery / 2.4 V Rechargeable Battery
• Transmission Frequency: Max. 1680 Transmitting Frequencies, Adjustable in 25 kHz Steps
• AF Frequency Response: 80 – 18000 Hz (Mic) / 25 - 18000 Hz (Line)
ME 4 Specifications:
• Connector: 3.5 mm Jack
• Frequency Response: 50 - 18000 Hz
• Max. SPL: 120 dB
• Cable Length App: 1.60 m
• Transducer Principle: Pre-Polarized Condensor Microphone
• Pick-Up Pattern: Cardioid
• Sensitivity in Free Field, No Load (1kHz): 40 mV/Pa
• Equivalent Noise Level: 31 dB
