Proel QUAD400

High-quality STARQUAD microphone cable, 4 twisted conductors with antiabrasive antistatic overall jacket - O.F.C. (Oxygen Free Copper)


Application fields : Microphone connections Audio signal connections
Conductors : Bare copper 23 AWG = 28 x 0.10 mm (0.22 mm2)
Insulation : XLPE 1.20 mm
Display : Cotton tape
Red spiral copper > 90%
Drain wire : Tinned copper
24 AWG = 7 x 0.15 mm (0.22 mm2)
Jacket : Flexible PVC 64 shore 5.20 mm
Conductor resistance : 84 Ohm/Km @ 20°C
Shied resistance : 18 Ohm/Km @ 20°C
Conductor/conductor capacitance : 50.5 pF/mt @ 1 KHz
Conductor/shield capacitance : 44.0 pF/mt @ 1 KHz
Nominal Impedance : 75 ± 3 Ohm
Attenuation : 12 MHz = 0.30 dB/100 mt
Velocity of propagation : 80 %
Operating temperature : -20°C / +70°C
Working voltage : 50 V
Weight : 38 Kg/Km
Minumum bendig radius : 20x cable section radius
Colours Available : Black
