Electro-Voice S-40 B - Black (1 piece!!)

​S-40/W • Ultracompact • 5.25" 2-Way Passive Full-Range Loudspeaker • 120 W • White • Price per Piece


Delivering high performance in an ultra-compact package, the S series is ideal for both distributed and near-field applications requiring high-quality sound. The two-way short-throw system is housed in an optimally vented, high-impact polystyrene enclosure that is suited for installation both indoors and out. Lows are handled by a 5.25- inch direct-radiating woofer with a polypropylene cone, while the high-frequency section is a one-inch direct-radiating soft-dome tweeter that is ferrofluid cooled. Built-in automatic power limiting independently protects each driver from unsafe transients. With mounting options that are flexible enough for virtually any application, the S series is perfect for anything from background and foreground music in restaurants and clubs to near-field monitoring in control rooms and broadcast studios.

Technical Specifications:

• Weight Net: 2.6 kg
• Depth: 150 mm
• Width: 178 mm
• Height: 249 mm
• Chassis Size: 133.35 mm
• Coverage (Nominal -6 dB) H: 100°
• Coverage (Nominal -6 dB) V: 100°
• Crossover Frequency: 3500 Hz
• Directivity Index: 9.8dB ((+3.8/-3.6 dB), 2 – 20000 Hz)
• Enclosure Material: High Impact Polystyrene Composite
• Frequency Response (-3 dB): 85 - 20000 (+/-3 dB)
• HF Transducer: 1-inch Softdome
• Input Connections: Spring Terminal
• LF Transducer: 5.25-inch
• Max. SPL/1m (Calc): 113dB
• Minimum Impedance: 3.7 Ohms
• Nominal Impedance (Passive): 4 Ohms
• Passive Power Handling: 30 W Peak
• Power Rating: 120 W
• Powered or Passive: Passive
• Sensitivity 1 W/1 m: 85dB
• Speaker Type: Monitor
• System Power Handling (Continuous/Program/Peak): 120/480Watts (Short Term/Long Term)
• Weatherized: No
