Electro-Voice ELX200-15

​1200 W (peak), 130 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing
1.4 inch DH-1C (1 inch exit) titanium compression driver
High-output EVS-15M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction
EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading

Axial Sensitivity (SPL, 1 W @ 1 m) 95dB
Coverage (Nominal -6 dB) H 90°
Coverage (Nominal -6 dB) V 60°
Crossover Frequency 1.6 kHz
Depth 384mm (15.12")
Enclosure Material Polypropylene composite
Family ELX200
Frequency Range (-10 dB) 52 Hz - 19 kHz
Frequency Response (-3 dB) 77 Hz - 16 kHz
Grille 18 AWG steel with powdercoat
Height 710mm (27.95")
HF Transducer DH-1C 1-inch titanium compression driver
LF Transducer EVS-15M 381 mm (15 in)
Max. SPL/1m (calc) 130dB
Minimum Impedance 7.0?
Nominal Impedance 8?
Power Handling (Continuous / Peak) 300W/1200W
Power Rating 1200W
Recommended High-Pass Frequency 42Hz
Shipping Weight 21.4kg (47.18 lbs)
Speaker Type Full-Range
Suspension (3) M10 suspension points
